TRITON® [WPBK] Waterproof Backer Board combines our patented MgO tile backer technology with a factory-applied waterproof and vapor barrier membrane, delivering an all-in-one solution that replaces both cement backer board and separate waterproofing layers.
Engineered for showers, bathrooms, and any moisture-prone application, it maintains a true watertight seal across floors, walls, and ceilings. Lightweight and easy to score and snap, it installs faster than traditional cement board without compromising performance.
ICC-ES certified and compliant with ANSI A118.10. Mold resistant. Free of crystalline silica and VOCs. Built to code, built to last.
Weight/Unit:
27.8 lbs
SKU:
TWB05035B
Weight/Unit:
59.2 lbs
SKU:
TWB05048B
|
PROPERTY
|
TEST METHOD
|
3'x5'
|
4'x8'
|
|---|---|---|---|
|
Thickness
|
----
|
.45 in.
|
.45 in.
|
|
Density (Specific Gravity)
|
----
|
0.75
|
0.75
|
|
Weight
|
----
|
1.85 lbs/ft² (27.8 lbs.)
|
1.85 lbs/ft² (59.2 lbs.)
|
|
Flexural Strength
|
ASTM C 1185
|
>1,000 psi
|
>1,000 psi
|
|
Mold Resistance
|
ASTM G 21
|
0
|
0
|
|
Surface Burning Characteristics
|
ASTM E 84
|
0/0
|
0/0
|
|
Moisture Transmission Rate
|
ASTM E96
|
<0.075
|
<0.075
|
Used as a tile backer, TRITON® MgO panels go up faster, with fewer steps, and fit entirely within your crew’s current skill set. The boards score and snap cleanly with a standard utility knife, so there are no wet saws or special blades required. If they’ve been installing cement backer board, they’re going to love working with Triton MgO.
